Product Summary

The TMS34010FNL-50 is an advanced high-performance CMOS 32-bit microprocessor optimized for graphics display systems. With a built-in instruction cache, the ability to simultaneously access memory and registers, and an instruction set designed specifically for raster graphics operation, the TMS34010FNL-50 provides user-programmable control of the CRT interface as well as the memory interface. The TMS34010FNL-50 is exceptionally well-supported by graphics software interface standards.

Parametrics

TMS34010FNL-50 absolute maximum ratings: (1)supply votlage, VCC: 7V; (2)input voltage range: -0.3 to 20V; (3)off-state output voltage range: -2 to 7V; (4)opeating free-air temperature range: 0 to 70℃; (5)storage temperature range: -10 to 150℃.

Features

TMS34010FNL-50 features: (1)fully programmable 32-bit general-purpose processor with 128-Megabyte address range; (2)pixel processing, XY addressing, and window checking built into the instruction set; (3)programmable 1, 2, 4, 8, or 16-bit pixel size with 16 boolean and 6 arithmetic pixel processing options; (4)30 general-purpose 32-bit registers and 32-bit stack pointer; (5)256-byte LRU on-chip instruction cache; (6)direct interfacing to both conventional DRAM and multiport video RAM; (7)dedicated 8/16 bit host processor interface and HOLD/HLDA interface; (8)programmable CRT control HSYNC; (9)high-level language support; (10)full line of hardware and software development tools including a C complier; (11)68-leaded packaging.
