DS18S20

High Precision, 1-Wire Digital Thermometer, TO92, Alarm search command identifies

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~1.15 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~1.15

PartNumber:: DS18S20

Brand:: Dallas Semiconductor - Maxim | Pack: TO | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Benson Ou's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-09-23

From Other Seller

Part Number:DS18S20
US $1.00 - 1.15
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
2DI75D-050A

US $16.00 - 30.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The DS18S20 is a High Precision 1-Wire Digital Thermometer. It provides 9bit temperature readings which indicate the temperature of the device. Because each DS18S20 contains a unique silicon serial number, multiple DS18S20s can exist on the same 1-Wire bus. This allows for placing temperature sensors in many different places. Applications where this feature is useful include HVAC environmental controls, sensing temperatures inside buildings, equipment or machinery, and process monitoring and control. Applications include thermostatic controls, industrial systems, consumer products, thermometers, or any thermally sensitive system.

Parametrics

DS18S20 absolute maximum ratings: (1)Voltage on Any Pin Relative to Ground:–0.5V to +6.0V; (2)Operating Temperature:–55℃ to +125℃; (3)Storage Temperature:–55℃ to +125℃.

Features

DS18S20 features: (1)Unique 1–Wire interface requires only one port pin for communication; (2)Multidrop capability simplifies distributed temperature sensing applications; (3)Requires no external components; (4)Can be powered from data line.Power supply range is 3.0V to 5.5V; (5)Zero standby power required; (6)Measures temperatures from –55℃ to +125℃; (7)±0.5℃ accuracy from –10℃ to +85℃; (8)Temperature is read as a 9–bit digital value; (9)Converts temperature to digital word in 750 ms (max.); (10)User–definable, nonvolatile temperature alarm settings; (11)Alarm search command identifies and addresses devices whose temperature is outside of programmed limits (temperature alarm condition); (12)Functionally compatible with DS1820 1-Wire digital thermometer; (13)Applications include thermostatic controls, industrial systems, consumer products, thermometers, or any thermally sensitive system.
