TMS320F2806PZA

Digital Signal Processor, 100-LQFP, - 0.3 V to 4.6 V, highly integrated, high-performance

Rated 5 Rating 5 | reviews | Write a review

Price:: US $10.00~11.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $10.00~11.00

PartNumber:: TMS320F2806PZA

Brand:: Texas Instruments - TI | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Benson Ou's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-08-02

From Other Seller

Part Number:TMS320F2806PZA
US $10.00 - 11.00
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The TMS320F2806PZA is a highly integrated, high-performance Digital Signal Processor for demanding control applications.

Parametrics

TMS320F2806PZA absolute maximum ratings: (1)Supply voltage range, VDDIO, VDD3VFL: - 0.3 V to 4.6 V with respect to VSS; (2)Supply voltage range, VDDA2, VDDAIO: - 0.3 V to 4.6 V with respect to VSSA; (3)Supply voltage range, VDD: - 0.3 V to 2.5 V with respect to VSS; (4)Supply voltage range, VDD1A18, VDD2A18: - 0.3 V to 2.5 V with respect to VSSA; (5)Supply voltage range, VSSA2, VSSAIO, VSS1AGND, VSS2AGND: - 0.3 V to 0.3 V with respect to VSS; (6)Input voltage range, VIN: - 0.3 V to 4.6 V; (7)Output voltage range, VO: - 0.3 V to 4.6 V; (8)Input clamp current, IIK (VIN < 0 or VIN > VDDIO): ± 20 mA; (9)Output clamp current, IOK (VO < 0 or VO > VDDIO): ± 20 mA; (10)Operating ambient temperature ranges, TA: A version: - 40℃ to 85℃; (11)Junction temperature range, Tj: - 40℃ to 150℃; (12)Storage temperature range, Tstg: - 65℃ to 150℃.

Features

TMS320F2806PZA features: (1)High-Performance Static CMOS Technology: 100 MHz (10-ns Cycle Time), Low-Power (1.8-V Core, 3.3-V I/O) Design, 3.3-V Flash Voltage; (2)JTAG Boundary Scan Support; (3)High-Performance 32-Bit CPU (TMS320C28x): 16 x 16 and 32 x 32 MAC Operations, 16 x 16 Dual MAC, Harvard Bus Architecture, Atomic Operations; (4)Boot ROM (4K x 16): With Software Boot Modes (via SCI, SPI, CAN, I2C, and Parallel I/O), Standard Math Tables.
